Home > Products > Pipe Fittings > Hard pipe Fittings > Metric ferrule connector

WFS SAE Right angle flange connector

Product:

WFS SAE Right angle flange connector

Description:

complies with lSO8434-1,24 ferrule connection
Commonly available carbon steel/galvanized surface, stainless steel
3000 PSl series

Consult Now

+86 0551-67291852

Product Details

complies with lSO8434-1,24 ferrule connection

Commonly available carbon steel/galvanized surface, stainless steel

3000 PSl series                                                                                                                                                                                       WFS SAE Right angle flange connector(图1)WFS SAE.pdf
