Home > Products > Test Connector Instrument > Sensor > Sensors

PR130 Pressure Sensors

Product:

PR130 Pressure Sensors

Description:

Working principle: Piezoresistive effect
Pressure type: relative pressure
Output signal: 4~20mA/0~10VDC
Electrical connection: 4-pin plug, M12x1
Mechanical connection:G1/4A, 1S0 228
Sealing material: DlN3689 standard seal, fluororubber
Protection grade: lP67
Casing material: non-corrosive high-strength steel
Membrane material: non-corrosive high-strength steel
Tightening torque: 40Nm(±5Nm)
Net weight:~85g

Consult Now

+86 0551-67291852

Product Details

Working principle: Piezoresistive effect

Pressure type: relative pressure

Output signal: 4~20mA/0~10VDC

Electrical connection: 4-pin plug, M12x1

Mechanical connection:G1/4A, 1S0 228

Sealing material: DlN3689 standard seal, fluororubber

Protection grade: lP67

Casing material: non-corrosive high-strength steel

Membrane material: non-corrosive high-strength steel

Tightening torque: 40Nm(±5Nm)

Net weight:~85g                                                                                                                                                                                   PR130 Pressure Sensors(图1)PR130.pdf
