PR190 Pressure Sensors

Product:

PR190 Pressure Sensors

Description:

Working principle: Piezoresistive effect
Pressure type: relative pressure
Output signal: 4~20mA/0~10VDC
Electrical connection: open cable head, 4 wires, length 1.5m
Mechanical connection: G1/4A, 1S0 228
Sealmaterial:DlN3689 standard seal, fluororubber
Protection grade: lP68K
Casing material: non-corrosive high-strength steel
Membrane material: non-corrosive high-strength steel
Tightening torque: 40Nm (±5Nm)
Net weight:~120g

Consult Now

+86 0551-67291852

Product Details

Working principle: Piezoresistive effect

Pressure type: relative pressure

Output signal: 4~20mA/0~10VDC

Electrical connection: open cable head, 4 wires, length 1.5m

Mechanical connection: G1/4A, 1S0 228

Sealmaterial:DlN3689 standard seal, fluororubber

Protection grade: lP68K

Casing material: non-corrosive high-strength steel

Membrane material: non-corrosive high-strength steel

Tightening torque: 40Nm (±5Nm)

Net weight:~120g                                                                                                                                                                             PR190 Pressure Sensors(图1)PR190.pdf
